%pip install numpy pandas lightningchart

Downloaded the dataset from https://www.sec.gov/data-research/sec-markets-data/financial-statement-data-sets

# Import necessary libraries (load pandas library to preprocess dataset)
import pandas as pd

# Chart 1 — Histogram of NetIncomeLoss Distribution (from num_clean.csv)
# Developed with AI Assistance to demonstrate LightningChart Python

import lightningchart as lc
import pandas as pd
import numpy as np

# Load license
with open("D:/HAMK/Internship/MyProjects/lc_license.txt", "r") as f:
    lc.set_license(f.read().strip())

# Load cleaned dataset
num = pd.read_csv("num_clean.csv", low_memory=False)

# Filter to NetIncomeLoss and prep values
net = num[num["tag"].astype(str) == "NetIncomeLoss"].copy()
net["value"] = pd.to_numeric(net["value"], errors="coerce")
values = net["value"].dropna().to_numpy(dtype=float)

if values.size == 0:
    raise ValueError("No NetIncomeLoss values found in num_clean.csv. Check preprocessing or tag filtering.")

# Optional clipping to reduce extreme tails for readability
CLIP = True
if CLIP:
    p_low, p_high = np.nanpercentile(values, [1, 99])
    values = np.clip(values, p_low, p_high)
    clip_note = " (clipped 1–99%)"
else:
    clip_note = ""

# Build 10 quantile (decile) bins
cats = pd.qcut(values, q=10, duplicates="drop")

# Convert to Series before counting
counts = pd.Series(cats).value_counts(sort=False)

# Extract decile edges
intervals = counts.index.to_list()  # pandas.Interval objects

def fmtB(v):
    b = v / 1e9
    if abs(b) >= 100:
        return f"{b:.0f}B"
    elif abs(b) >= 10:
        return f"{b:.1f}B"
    else:
        return f"{b:.2f}B"

bar_data = []
for i, (iv, cnt) in enumerate(zip(intervals, counts.values), start=1):
    left, right = float(iv.left), float(iv.right)
    label = f"Q{i}: {fmtB(left)}–{fmtB(right)}"
    bar_data.append({"category": label, "value": int(cnt)})

# Create BarChart (quantile histogram)
chart = lc.BarChart(
    vertical=True,
    theme=lc.Themes.Light,
    title=f"NetIncomeLoss Distribution — Decile bins (X: Net income in USD, Y: Filing count){clip_note}"
)

chart.set_data(bar_data)
chart.set_sorting('disabled')   # keep Q1..Q10 order
# chart.set_bars_color('cyan')  # optional

chart.open()

# Chart 2 – Scatter Plot of Revenues vs NetIncomeLoss
# Developed with AI Assistance to demonstrate LightningChart Python

import lightningchart as lc
import pandas as pd
import numpy as np

# Load license (adjust path if needed)
with open("D:/HAMK/Internship/MyProjects/lc_license.txt", "r") as f:
    lc.set_license(f.read().strip())

# Load + pivot so each row (adsh) has both metrics
num = pd.read_csv("num_clean.csv", low_memory=False)
keep = num[num["tag"].isin(["Revenues", "NetIncomeLoss"])].copy()
keep["value"] = pd.to_numeric(keep["value"], errors="coerce")
keep = keep.dropna(subset=["value"])

pivot = (
    keep.pivot_table(index="adsh", columns="tag", values="value", aggfunc="max")
         .dropna(subset=["Revenues", "NetIncomeLoss"])
         .reset_index()
)

if pivot.empty:
    raise ValueError("No filings contain both Revenues and NetIncomeLoss in num_clean.csv.")

# Scale to USD billions for readability
pivot["Revenues_B"] = pivot["Revenues"] / 1e9
pivot["NetIncomeLoss_B"] = pivot["NetIncomeLoss"] / 1e9

# Optional clipping to reduce extreme tails (toggle False to see full range)
CLIP = True
x = pivot["Revenues_B"].to_numpy(float)
y = pivot["NetIncomeLoss_B"].to_numpy(float)

if CLIP:
    x1, x99 = np.nanpercentile(x, [1, 99])
    y1, y99 = np.nanpercentile(y, [1, 99])
    x = np.clip(x, x1, x99)
    y = np.clip(y, y1, y99)
    clip_note = " (clipped 1–99%)"
else:
    clip_note = ""

# Build chart
chart = lc.ChartXY(title=f"Revenues vs Net Income — Scatter{clip_note}", theme=lc.Themes.Dark)

# Scatter series
pts = chart.add_point_series()

# Color points by NetIncomeLoss (y)
# Build a dynamic palette spanning min → 0 → upper quantile → max
y_min, y_q75, y_max = float(np.nanmin(y)), float(np.nanpercentile(y, 75)), float(np.nanmax(y))
pts.set_palette_point_coloring(
    steps=[
        {"value": y_min, "color": ("darkblue")}, # deep losses
        {"value": 0.0, "color": ("lightblue")}, # break-even
        {"value": y_q75, "color": ("orange")}, # strong profits
        {"value": y_max, "color": ("red")},
    ],
    look_up_property="y",
    percentage_values=False
)

# Add data
pts.add(x=x, y=y)

# Axis titles
chart.get_default_x_axis().set_title("Revenues (USD billions)")
chart.get_default_y_axis().set_title("Net income (USD billions)")

chart.open()

# Chart 3 – Bar Chart of Quarterly Operating Cash Flow
# Developed with AI Assistance to demonstrate LightningChart Python

import lightningchart as lc
import pandas as pd
import numpy as np

# Load license
with open("D:/HAMK/Internship/MyProjects/lc_license.txt", "r") as f:
    lc.set_license(f.read().strip())

# Load raw files (need fp from sub)
num = pd.read_csv("num.csv", encoding="ISO-8859-1", low_memory=False)
sub = pd.read_csv("sub.csv", encoding="ISO-8859-1", low_memory=False)

# Filter Operating Cash Flow tag
num["tag"] = num["tag"].astype(str)
ocf = num[num["tag"].str.fullmatch("NetCashProvidedByUsedInOperatingActivities", case=False, na=False)].copy()

ocf["value"] = pd.to_numeric(ocf["value"], errors="coerce")
ocf = ocf.dropna(subset=["value"])

# Keep USD where available
if "uom" in ocf.columns:
    ocf["uom"] = ocf["uom"].astype(str).str.upper()
    ocf = ocf[ocf["uom"].isin({"USD", "USD$", "US DOLLARS", "US$"})]

# Join quarter label from sub (`fp`), or infer from `ddate`
ocf["adsh"] = ocf["adsh"].astype(str).str.strip()
sub["adsh"] = sub["adsh"].astype(str).str.strip()
ocf = ocf.merge(sub[["adsh", "fp"]], on="adsh", how="left")

if "ddate" in ocf.columns:
    ocf["ddate"] = pd.to_datetime(ocf["ddate"].astype(str), errors="coerce", format="%Y%m%d")

def to_quarter(row):
    fp = str(row.get("fp", "")).upper()
    if fp in {"Q1", "Q2", "Q3", "Q4"}:
        return fp
    dt = row.get("ddate")
    if pd.notna(dt):
        return f"Q{int(((dt.month - 1)//3) + 1)}"
    return np.nan

ocf["quarter"] = ocf.apply(to_quarter, axis=1)
ocf = ocf[ocf["quarter"].isin(["Q1", "Q2", "Q3", "Q4"])]

# OPTIONAL: if multiple OCF facts per filing, keep the latest
if "ddate" in ocf.columns:
    ocf = ocf.sort_values(["adsh", "ddate"]).groupby("adsh", as_index=False).tail(1)

# Aggregate: median per quarter (robust), then scale
agg = ocf.groupby("quarter")["value"].median().reindex(["Q1", "Q2", "Q3", "Q4"])
agg_B = (agg / 1e9).fillna(0.0)

# Prepare BarChart data
bar_data = [{"category": q, "value": float(v)} for q, v in agg_B.items()]

# Plot
chart = lc.BarChart(
    vertical=True,
    theme=lc.Themes.Dark,
    title="Quarterly Operating Cash Flow - Median per quarter (X: Quarter, Y: USD Billions)"
)
chart.set_sorting("disabled")   # Q1..Q4 order
chart.set_data(bar_data)
# chart.set_bars_color('#22d3ee')  # optional

chart.open()

# Chart 5 – Line Chart of Revenues Over Time
# Developed with AI Assistance to demonstrate LightningChart Python

import lightningchart as lc
import pandas as pd
import numpy as np

# License (adjust if needed)
with open("D:/HAMK/Internship/MyProjects/lc_license.txt", "r") as f:
    lc.set_license(f.read().strip())

# Load data
num = pd.read_csv("num_clean.csv", low_memory=False)
# Use sub.csv because it reliably includes 'filed'/'accepted' in the raw dump
sub = pd.read_csv("sub.csv", encoding="ISO-8859-1", low_memory=False)

# Revenues per filing
rev_rows = num[num["tag"].astype(str) == "Revenues"].copy()
rev_rows["value"] = pd.to_numeric(rev_rows["value"], errors="coerce")
rev_rows = rev_rows.dropna(subset=["value"])

# Keep one revenue per filing (max if multiple facts)
rev = rev_rows.groupby("adsh", as_index=False)["value"].max()

# Merge possible date columns from sub
sub_dates = sub[["adsh", "filed", "accepted", "period"]].copy()
rev = rev.merge(sub_dates, on="adsh", how="left")

# Also bring in ddate from num as last fallback
rev_ddate = (
    rev_rows[["adsh", "ddate"]]
    .dropna()
    .drop_duplicates(subset=["adsh"], keep="last")
)
rev = rev.merge(rev_ddate, on="adsh", how="left")

# Build a single datetime column with fallbacks
def parse_ymd(s):
    return pd.to_datetime(str(s), errors="coerce", format="%Y%m%d")

rev["filed_dt"]    = parse_ymd(rev["filed"])
rev["accepted_dt"] = pd.to_datetime(rev["accepted"], errors="coerce")  # already timestamp-like
rev["period_dt"]   = parse_ymd(rev["period"])
rev["ddate_dt"]    = pd.to_datetime(rev["ddate"], errors="coerce", format="%Y%m%d")

rev["date"] = rev["filed_dt"]
rev.loc[rev["date"].isna(), "date"] = rev.loc[rev["date"].isna(), "accepted_dt"]
rev.loc[rev["date"].isna(), "date"] = rev.loc[rev["date"].isna(), "period_dt"]
rev.loc[rev["date"].isna(), "date"] = rev.loc[rev["date"].isna(), "ddate_dt"]

# Drop rows with no usable date
rev = rev.dropna(subset=["date"])
if rev.empty:
    raise ValueError("No valid dates found (filed/accepted/period/ddate). Check your sub/num files.")

# Aggregate to weekly median (robust)
weekly = (
    rev.set_index("date")
       .groupby(pd.Grouper(freq="W-MON"))["value"]
       .median()
       .dropna()
)
# Fallback to daily if very sparse
if weekly.size < 3:
    weekly = (
        rev.set_index("date")
           .groupby(pd.Grouper(freq="D"))["value"]
           .median()
           .dropna()
    )

# Build series data (X as POSIX seconds, Y in USD billions)
y_vals = (weekly / 1e9).to_numpy(dtype=float)
x_vals = (weekly.index.astype("int64") // 10**9).to_numpy(dtype=float)

# Plot
chart = lc.ChartXY(theme=lc.Themes.Light, title="Revenues Over Time - Weekly median (USD billions)")
line = chart.add_line_series()
line.append_samples(x_values=x_vals, y_values=y_vals)

# Axes
x_axis = chart.get_default_x_axis()
y_axis = chart.get_default_y_axis()
y_axis.set_title("Revenues (USD billions)")

# Use date ticks if available
try:
    x_axis.set_tick_strategy(lc.AxisTickStrategies.DateTime)
    x_axis.set_title("Filing date")
except Exception:
    x_axis.set_title("Time (POSIX seconds)")

chart.open()

# Chart 6 – Stacked Bar Chart of Liabilities (Current vs Noncurrent)
# Developed with AI Assistance to demonstrate LightningChart Python

import lightningchart as lc
import pandas as pd
import numpy as np

# Load license
with open("D:/HAMK/Internship/MyProjects/lc_license.txt", "r") as f:
    lc.set_license(f.read().strip())

# Load raw SEC files (need balance-sheet tags + quarter labels)
num = pd.read_csv("num.csv", encoding="ISO-8859-1", low_memory=False)
sub = pd.read_csv("sub.csv", encoding="ISO-8859-1", low_memory=False)

num["tag"] = num["tag"].astype(str)
num["adsh"] = num["adsh"].astype(str).str.strip()
sub["adsh"] = sub["adsh"].astype(str).str.strip()

# Keep only the tags we need
tags = ["Liabilities", "LiabilitiesCurrent", "LiabilitiesNoncurrent"]
df = num[num["tag"].isin(tags)].copy()

# Numeric + USD filter
df["value"] = pd.to_numeric(df["value"], errors="coerce")
df = df.dropna(subset=["value"])
if "uom" in df.columns:
    df["uom"] = df["uom"].astype(str).str.upper()
    df = df[df["uom"].isin({"USD", "USD$", "US DOLLARS", "US$"})]

# If multiple ddates per (adsh, tag), keep the latest
if "ddate" in df.columns:
    df["ddate"] = pd.to_datetime(df["ddate"].astype(str), errors="coerce", format="%Y%m%d")
    df = df.sort_values(["adsh", "tag", "ddate"]).groupby(["adsh", "tag"], as_index=False).tail(1)

# Pivot to one row per filing
wide = df.pivot_table(index="adsh", columns="tag", values="value", aggfunc="max")

# Derive current & noncurrent liabilities per filing
def split_liabilities(row):
    cur  = row.get("LiabilitiesCurrent", np.nan)
    nonc = row.get("LiabilitiesNoncurrent", np.nan)
    total = row.get("Liabilities", np.nan)

    # If both provided, use them.
    if pd.notna(cur) and pd.notna(nonc):
        return cur, nonc
    # If total + one component, infer the other.
    if pd.notna(total) and pd.notna(cur):
        nonc_inf = total - cur
        return cur, (nonc_inf if np.isfinite(nonc_inf) else np.nan)
    if pd.notna(total) and pd.notna(nonc):
        cur_inf = total - nonc
        return (cur_inf if np.isfinite(cur_inf) else np.nan), nonc
    # Otherwise, insufficient info.
    return np.nan, np.nan

cur_vals, nonc_vals = [], []
for _, row in wide.iterrows():
    c, n = split_liabilities(row)
    cur_vals.append(c); nonc_vals.append(n)

wide = wide.assign(Liab_Current=cur_vals, Liab_Noncurrent=nonc_vals)
wide = wide[(wide["Liab_Current"].notna()) | (wide["Liab_Noncurrent"].notna())].reset_index()

# Attach quarter labels (prefer sub.fp; else infer from sub.filed)
sub_small = sub[["adsh", "fp", "filed"]].copy()
wide = pd.merge(wide, sub_small, on="adsh", how="left")

# Parse fallback date to infer quarter if needed
def to_quarter(fp, filed):
    fp = str(fp).upper()
    if fp in {"Q1", "Q2", "Q3", "Q4"}:
        return fp
    dt = pd.to_datetime(str(filed), errors="coerce", format="%Y%m%d")
    if pd.notna(dt):
        return f"Q{int(((dt.month - 1)//3) + 1)}"
    return np.nan

wide["quarter"] = [to_quarter(fp, filed) for fp, filed in zip(wide["fp"], wide["filed"])]
wide = wide[wide["quarter"].isin(["Q1", "Q2", "Q3", "Q4"])]

if wide.empty:
    raise ValueError("No filings with usable Liabilities split and quarter labels.")

# Aggregate to median per quarter (USD billions)
agg = (
    wide.groupby("quarter")[["Liab_Current", "Liab_Noncurrent"]]
        .median()
        .reindex(["Q1","Q2","Q3","Q4"])
        / 1e9
)
agg = agg.fillna(0.0)

categories = agg.index.tolist()  # ["Q1","Q2","Q3","Q4"]
current_vals = agg["Liab_Current"].astype(float).tolist()
noncurrent_vals = agg["Liab_Noncurrent"].astype(float).tolist()

# Plot stacked bars
chart = lc.BarChart(
    vertical=True,
    theme=lc.Themes.Light,
    title="Liabilities Structure by Quarter (X: Quarter, Y: USD Billions, median per filing)"
)

chart.set_sorting("disabled")  # keep Q1..Q4 order
chart.set_data_stacked(
    categories,
    [
        {"subCategory": "Current",    "values": current_vals},
        {"subCategory": "Noncurrent", "values": noncurrent_vals},
    ],
)
chart.add_legend().add(chart)

chart.open()

# Chart 7 – Box Plot of Gross Profit Margin by Industry
# Developed with AI Assistance to demonstrate LightningChart Python

import lightningchart as lc
import pandas as pd
import numpy as np

# Load your license
with open("D:/HAMK/Internship/MyProjects/lc_license.txt", "r") as f:
    lc.set_license(f.read().strip())

# Load data
num = pd.read_csv("num_clean.csv", low_memory=False)
sub = pd.read_csv("sub_clean.csv", low_memory=False)   # needs 'sic'

# Keep Revenues & GrossProfit, one value per filing
df = num[num["tag"].isin(["Revenues", "GrossProfit"])].copy()
df["value"] = pd.to_numeric(df["value"], errors="coerce")
df = df.dropna(subset=["value"])

wide = (
    df.pivot_table(index="adsh", columns="tag", values="value", aggfunc="max")
      .dropna(subset=["Revenues", "GrossProfit"])
      .reset_index()
)

# Merge SIC
sub_small = sub[["adsh", "sic"]].copy()
sub_small["adsh"] = sub_small["adsh"].astype(str).str.strip()
wide["adsh"] = wide["adsh"].astype(str).str.strip()
wide = wide.merge(sub_small, on="adsh", how="left")

# Map SIC → division (compact)
def sic_to_division(s):
    try:
        s = int(s)
    except: return "Other"
    if   100 <= s <=  999:  return "Ag"
    if  1000 <= s <= 1499:  return "Mining"
    if  1500 <= s <= 1799:  return "Const"
    if  2000 <= s <= 3999:  return "Mfg"
    if  4000 <= s <= 4999:  return "Trans"
    if  5000 <= s <= 5199:  return "Wh"
    if  5200 <= s <= 5999:  return "Retail"
    if  6000 <= s <= 6799:  return "Fin"
    if  7000 <= s <= 8999:  return "Svc"
    if  9000 <= s <= 9729:  return "Public"
    return "Other"

wide["industry"] = wide["sic"].apply(sic_to_division)

# Gross Profit Margin (%), clip for readability
rev = wide["Revenues"].replace(0, np.nan)
gpm = (wide["GrossProfit"] / rev) * 100.0
wide["gpm_pct"] = gpm.replace([np.inf, -np.inf], np.nan)
wide = wide.dropna(subset=["gpm_pct"])
wide["gpm_pct"] = wide["gpm_pct"].clip(-100, 100)

# Top 6 industries by count
top_inds = (
    wide.groupby("industry")["gpm_pct"].size()
        .sort_values(ascending=False).head(6).index.tolist()
)
plot_df = wide[wide["industry"].isin(top_inds)].copy()
if plot_df.empty:
    raise ValueError("No gross profit margin data after filtering. Check num_clean.csv contents.")

# Create chart
chart = lc.ChartXY(theme=lc.Themes.Light, title="Gross Profit Margin by Industry — Box Plot (%)")

# Prepare box data with extra spacing + short labels
SPACING = 3  # widen distance between categories to avoid overlap
dataset, x_out, y_out = [], [], []

for i, cat in enumerate(top_inds):
    vals = plot_df.loc[plot_df["industry"] == cat, "gpm_pct"].dropna().to_numpy()
    if vals.size < 2:
        continue

    start = (i * SPACING) + 1
    end = start + 1

    q1 = float(np.percentile(vals, 25))
    q3 = float(np.percentile(vals, 75))
    med = float(np.median(vals))
    iqr = q3 - q1
    lo_b, hi_b = q1 - 1.5 * iqr, q3 + 1.5 * iqr

    inliers = vals[(vals >= lo_b) & (vals <= hi_b)]
    if inliers.size == 0:
        inliers = np.array([q1, q3], dtype=float)

    dataset.append({
        "start": start, "end": end,
        "lowerQuartile": q1, "upperQuartile": q3,
        "median": med,
        "lowerExtreme": float(inliers.min()),
        "upperExtreme": float(inliers.max()),
    })

    outs = vals[(vals < lo_b) | (vals > hi_b)]
    if outs.size:
        x_out += [start + 0.5] * outs.size
        y_out += outs.tolist()

# Add box series
series = chart.add_box_series()
series.add_multiple(dataset)

# Add outliers
out = chart.add_point_series(sizes=True)
out.set_point_color("red")
if y_out:
    out.append_samples(x_values=x_out, y_values=y_out, sizes=[9] * len(y_out))

# Axis titles
x_axis = chart.get_default_x_axis()
y_axis = chart.get_default_y_axis()
x_axis.set_title("Industry (SIC division, abbreviated)")
y_axis.set_title("Gross profit margin (%)")

# Custom ticks with short labels (no overlap)
try:
    # Set the visible range to fit all categories
    x_axis.set_interval(0, (len(top_inds) - 1) * SPACING + 3)
    for i, cat in enumerate(top_inds):
        tick = x_axis.add_custom_tick()
        tick.set_value((i * SPACING) + 1.5)  # centered between start & end
        tick.set_text(cat)                   # already short (e.g., Mfg, Retail)
except Exception:
    # If custom ticks aren't supported, print order to console
    print("Custom ticks not supported; category order:", top_inds)

chart.open()

# Chart 8 – Scatter Plot of Assets vs StockholdersEquity
# Developed with AI Assistance to demonstrate LightningChart Python

import lightningchart as lc
import numpy as np
import pandas as pd

# Load license
with open("D:/HAMK/Internship/MyProjects/lc_license.txt", "r") as f:
    lc.set_license(f.read().strip())

# Load numeric (need balance-sheet tags)
num = pd.read_csv("num.csv", encoding="ISO-8859-1", low_memory=False)

num["tag"] = num["tag"].astype(str)
num["adsh"] = num["adsh"].astype(str).str.strip()
num["value"] = pd.to_numeric(num["value"], errors="coerce")
num = num.dropna(subset=["value"])

# Keep only the tags we need
tags = [
    "Assets", "AssetsCurrent", "AssetsNoncurrent",
    "Liabilities",
    "StockholdersEquity",
    "StockholdersEquityIncludingPortionAttributableToNoncontrollingInterest",
]
df = num[num["tag"].isin(tags)].copy()

# If multiple dates per (adsh, tag), keep latest
if "ddate" in df.columns:
    df["ddate"] = pd.to_datetime(df["ddate"].astype(str), errors="coerce", format="%Y%m%d")
    df = df.sort_values(["adsh", "tag", "ddate"]).groupby(["adsh", "tag"], as_index=False).tail(1)

# Pivot to wide per filing
wide = df.pivot_table(index="adsh", columns="tag", values="value", aggfunc="max")

# Compute Assets (proxy) and Equity (choose best available)
def assets_proxy(row):
    if pd.notna(row.get("Assets")):
        return row["Assets"]
    ac, anc = row.get("AssetsCurrent"), row.get("AssetsNoncurrent")
    if pd.notna(ac) and pd.notna(anc):
        return ac + anc
    liab = row.get("Liabilities")
    eq = row.get("StockholdersEquity")
    if pd.isna(eq):
        eq = row.get("StockholdersEquityIncludingPortionAttributableToNoncontrollingInterest")
    if pd.notna(liab) and pd.notna(eq):
        return liab + eq
    return np.nan

def equity_value(row):
    if pd.notna(row.get("StockholdersEquity")):
        return row.get("StockholdersEquity")
    return row.get("StockholdersEquityIncludingPortionAttributableToNoncontrollingInterest")

wide["Assets_val"] = wide.apply(assets_proxy, axis=1)
wide["Equity_val"] = wide.apply(equity_value, axis=1)

data = wide[["Assets_val", "Equity_val"]].dropna()
if data.empty:
    raise ValueError("No filings with both Assets (direct/proxy) and Stockholders' Equity found in num.csv.")

# Scale to USD billions
x = (data["Assets_val"] / 1e9).to_numpy(float)
y = (data["Equity_val"] / 1e9).to_numpy(float)

# Optional clipping to reduce extreme tails
CLIP = True
if CLIP:
    x1, x99 = np.nanpercentile(x, [1, 99])
    y1, y99 = np.nanpercentile(y, [1, 99])
    x = np.clip(x, x1, x99)
    y = np.clip(y, y1, y99)
    clip_note = " (clipped 1–99%)"
else:
    clip_note = ""

# Plot
chart = lc.ChartXY(title=f"Assets vs Stockholders’ Equity - Scatter{clip_note}", theme=lc.Themes.Light)
pts = chart.add_point_series()

# Color by equity magnitude (y) for a bit of depth; safe for all builds
y_min, y_q75, y_max = float(np.nanmin(y)), float(np.nanpercentile(y, 75)), float(np.nanmax(y))
pts.set_palette_point_coloring(
    steps=[
        {"value": y_min, "color": ("#1e3a8a")},  # darker for low equity
        {"value": 0.0,   "color": ("#60a5fa")},  # near zero
        {"value": y_q75, "color": ("#f59e0b")},  # higher equity
        {"value": y_max, "color": ("#ef4444")},  # very high equity
    ],
    look_up_property="y",
    percentage_values=False
)

pts.add(x=x, y=y)

# Axes
chart.get_default_x_axis().set_title("Assets (USD billions)")
chart.get_default_y_axis().set_title("Stockholders’ equity (USD billions)")

chart.open()

# Chart 9 – Heatmap of Filing Frequency by Year and Form Type
# Developed with AI Assistance to demonstrate LightningChart Python

import lightningchart as lc
import numpy as np
import pandas as pd

# Load license
with open("D:/HAMK/Internship/MyProjects/lc_license.txt", "r") as f:
    lc.set_license(f.read().strip())

# Load submissions (forms + dates)
sub = pd.read_csv("sub.csv", encoding="ISO-8859-1", low_memory=False)
sub["adsh"] = sub["adsh"].astype(str).str.strip()
sub["form"] = sub["form"].astype(str).str.strip()

# Helpers
def get_col(df, name):
    return df[name] if name in df.columns else pd.Series([pd.NA] * len(df), index=df.index)
def parse_ymd_series(series):
    return pd.to_datetime(series.astype(str), errors="coerce", format="%Y%m%d")

# Build a single datetime (filed → accepted → period → fy)
dt = parse_ymd_series(get_col(sub, "filed"))
dt = dt.fillna(pd.to_datetime(get_col(sub, "accepted"), errors="coerce"))
dt = dt.fillna(parse_ymd_series(get_col(sub, "period")))
fy = pd.to_numeric(get_col(sub, "fy"), errors="coerce")
dt = dt.fillna(pd.to_datetime(fy, errors="coerce", format="%Y"))

sub = sub.assign(date=dt).dropna(subset=["date"])

# Prefer YEAR; if only 1 year in the slice, fallback to MONTH (YYYY-MM)
years_n = sub["date"].dt.year.nunique()
if years_n >= 2:
    y_field = "year"
    sub["year"] = sub["date"].dt.year.astype(int)
else:
    y_field = "month"
    sub["month"] = sub["date"].dt.to_period("M").astype(str)

# Keep top 8 forms; rest = "Other"
top_forms = sub["form"].value_counts().head(8).index.tolist()
sub["form_simpl"] = np.where(sub["form"].isin(top_forms), sub["form"], "Other")

# Pivot to Y×Form counts
counts = (
    sub.groupby([y_field, "form_simpl"]).size()
       .unstack(fill_value=0)
       .sort_index()
)

# Remove empty columns (no filings)
counts = counts.loc[:, counts.sum(axis=0) > 0]
if counts.empty:
    raise ValueError("No filing counts available after parsing sub.csv.")

# Intensity matrix (log + normalize to 0..1)
M = counts.to_numpy(dtype=float)
M_log = np.log1p(M)
m_min, m_max = float(M_log.min()), float(M_log.max())
if m_max == m_min:
    # Still flat → center fill to show up with legend, avoids “all green”
    M_norm = np.full_like(M_log, 0.5)
else:
    M_norm = (M_log - m_min) / (m_max - m_min)

# LightningChart heatmap expects a list shaped [columns][rows]
# We have rows=Y, cols=Forms -> transpose
intensity = M_norm.T.tolist()

rows = counts.shape[0]              # number of Y bins
cols = counts.shape[1]              # number of form columns
Y_labels = counts.index.tolist()    # Y axis labels (years or months)
X_labels = counts.columns.tolist()  # X axis labels (form types)

# LightningChart heatmap
chart = lc.ChartXY(
    title=f"Filing Frequency by {y_field.capitalize()} & Form Type - Heatmap",
    theme=lc.Themes.Light
)

heat = chart.add_heatmap_grid_series(columns=cols, rows=rows)
heat.set_start(x=0, y=0)
heat.set_end(x=cols, y=rows)
heat.set_step(x=1, y=1)
heat.set_intensity_interpolation(False)      # crisp cells
heat.invalidate_intensity_values(intensity)  # <- transposed list
heat.hide_wireframe()

# Palette 0→1
heat.set_palette_coloring(
    steps=[
        {"value": 0.00, "color": ("#eef2ff")},   # low
        {"value": 0.50, "color": ("#93c5fd")},   # mid
        {"value": 1.00, "color": ("#ef4444")},   # high
    ],
    look_up_property="value",
    interpolate=True
)

# Axes & labeled ticks (center each cell)
x_axis = chart.get_default_x_axis()
y_axis = chart.get_default_y_axis()
x_axis.set_title("Form type")
y_axis.set_title(y_field.capitalize())

try:
    x_axis.set_interval(0, cols)
    for i, f in enumerate(X_labels):
        t = x_axis.add_custom_tick(); t.set_value(i + 0.5); t.set_text(f)

    y_axis.set_interval(0, rows)
    for j, y in enumerate(Y_labels):
        t = y_axis.add_custom_tick(); t.set_value(j + 0.5); t.set_text(str(y))
except Exception:
    print("Forms (left→right):", X_labels)
    print(f"{y_field.capitalize()} (bottom→top):", Y_labels)

chart.add_legend(data=heat).set_title("Relative intensity")
chart.open()
