%pip install numpy pandas lightningchart

# Import necessary libraries (load pandas library to preprocess dataset)
import pandas as pd

# Chart 1A - Polar-style Rose per Asset (separate windows)
# Developed with AI assistance to demonstrate LightningChart Python

import lightningchart as lc
import re
import numpy as np
import pandas as pd

# License
with open("D:/HAMK/Internship/MyProjects/lc_license.txt", "r") as f:
     lc.set_license(f.read().strip())

try:
    ccd_clean
except NameError:
    ccd_clean = pd.read_csv("cryptocurrency.csv", encoding="latin1")
try:
    sd
except NameError:
    sd = pd.read_csv("stocks.csv", encoding="latin1")

def returns_from_frame(df, asset_col=None, time_col=None, price_col=None, open_col=None, close_col=None):
    d = df.copy()
    def norm(s): return re.sub(r'[^a-z0-9]', '', str(s).lower())
    colmap = {norm(c): c for c in d.columns}
    cols_norm = set(colmap.keys())

    def pick_exact(cands):
        return next((colmap[c] for c in cands if c in cols_norm), None)

    def pick_contains(subs):
        for cn in cols_norm:
            if any(sub in cn for sub in subs):
                return colmap[cn]
        return None

    asset_col = asset_col or pick_exact(['symbol','ticker']) or pick_contains(['symbol','ticker','asset','name'])
    time_col  = time_col  or pick_exact(['timestamp','datetime','date','time']) or pick_contains(['timestamp','datetime','date','time'])
    price_col = price_col or pick_exact(['priceusd','price','close','adjclose']) or pick_contains(['priceusd','closeprice','lastprice','last','close','price'])
    open_col  = open_col  or pick_exact(['open']) or pick_contains(['open'])
    close_col = close_col or pick_exact(['close','adjclose']) or pick_contains(['close','closing'])

    if asset_col is None or time_col is None:
        raise ValueError(f"Missing key columns. Found asset={asset_col}, time={time_col}")

    d[time_col] = pd.to_datetime(d[time_col], errors='coerce')
    d = d.dropna(subset=[time_col]).sort_values([asset_col, time_col])

    def to_num(x):
        return (x.astype(str).str.replace(r'[^0-9.\-]', '', regex=True).replace({'': np.nan}).astype(float))

    if price_col is not None:
        d[price_col] = to_num(d[price_col])
        d = d.dropna(subset=[price_col])
        d['ret_1h'] = d.groupby(asset_col, group_keys=False)[price_col].apply(lambda s: s.pct_change()*100.0)
    elif open_col is not None and close_col is not None:
        d[open_col], d[close_col] = to_num(d[open_col]), to_num(d[close_col])
        d = d.dropna(subset=[open_col, close_col])
        d['ret_1h'] = (d[close_col] - d[open_col]) / d[open_col] * 100.0
    else:
        raise ValueError("Provide a price column or both open & close columns.")

    d = d.dropna(subset=['ret_1h'])
    return d.rename(columns={asset_col:'symbol', time_col:'timestamp'})[['symbol','timestamp','ret_1h']]

crypto_ret = returns_from_frame(ccd_clean)
stock_ret  = returns_from_frame(sd)

crypto_ret['asset_class'] = 'Crypto'
stock_ret['asset_class']  = 'Stock'
rets = pd.concat([crypto_ret, stock_ret], ignore_index=True)

N = 4
top_assets = (rets.groupby('symbol').size().sort_values(ascending=False).head(N).index.tolist())
plot_df = rets[rets['symbol'].isin(top_assets)].copy()

BIN_COUNT = 72
ret_min = plot_df['ret_1h'].quantile(0.01)
ret_max = plot_df['ret_1h'].quantile(0.99)
if not np.isfinite(ret_min) or not np.isfinite(ret_max) or ret_min == ret_max:
    ret_min, ret_max = plot_df['ret_1h'].min(), plot_df['ret_1h'].max()
if ret_min == ret_max:
    ret_min, ret_max = -0.5, 0.5
bins = np.linspace(ret_min, ret_max, BIN_COUNT + 1)

def rose_polar_data(counts):
    counts = counts.astype(float)
    if counts.max() > 0:
        counts = counts / counts.max()
    angles = (np.arange(BIN_COUNT) + 0.5) * (360.0 / BIN_COUNT)

    angles = np.append(angles, angles[0])
    amplitudes = np.append(counts, counts[0])

    polar_data = [{'angle': float(angle), 'amplitude': float(amp)}
                  for angle, amp in zip(angles, amplitudes)]
    return polar_data

charts = []
for sym in top_assets:
    vals = plot_df.loc[plot_df['symbol'] == sym, 'ret_1h'].to_numpy()
    if vals.size == 0:
        continue

    counts, _ = np.histogram(vals, bins=bins)
    polar_data = rose_polar_data(counts)

    chart = lc.PolarChart(
        theme=lc.Themes.Light,
        html_text_rendering=True,
        title=f'Polar Rose - Hourly Return Distribution - {sym}\n(radius = relative frequency)'
    )

    for r in [1.0, 0.5]:
        angles_ref = np.linspace(0, 360, 360, endpoint=True)
        ref_data = [{'angle': float(angle), 'amplitude': float(r)} for angle in angles_ref]

        ref_series = chart.add_area_series()
        ref_series.set_name(f'Reference (r={r})')
        ref_series.set_data(ref_data)
        ref_series.set_stroke(thickness=1, color='#cccccc')

    series = chart.add_area_series()
    series.set_name(sym)
    series.set_data(polar_data)
    series.set_stroke(thickness=2)

    charts.append(chart)

for c in charts:
    c.open()

# Chart 1B - Histogram of Hourly Price Changes by Asset
# Developed with AI assistance to demonstrate LightningChart Python

import lightningchart as lc
import re
import numpy as np
import pandas as pd

# License
with open("D:/HAMK/Internship/MyProjects/lc_license.txt", "r") as f:
     lc.set_license(f.read().strip())

# Expect existing dataframes: ccd_clean (crypto) and sd (stocks)
try:
    ccd_clean
except NameError:
    ccd_clean = pd.read_csv("cryptocurrency.csv", encoding="latin1")

try:
    sd
except NameError:
    sd = pd.read_csv("stocks.csv", encoding="latin1")

# Helper: robust hourly returns
def returns_from_frame(df,
    asset_col=None, time_col=None,
    price_col=None, open_col=None, close_col=None
):
    """Return ['symbol','timestamp','ret_1h'] from a generic OHLC/Close frame."""
    d = df.copy()
    def norm(s): return re.sub(r'[^a-z0-9]', '', str(s).lower())
    colmap = {norm(c): c for c in d.columns}
    cols_norm = set(colmap.keys())
    def pick_exact(cands):
        for c in cands:
            if c in cols_norm:
                return colmap[c]
        return None
    def pick_contains(subs):
        for cn in cols_norm:
            if any(sub in cn for sub in subs):
                return colmap[cn]
        return None

    if asset_col is None:
        asset_col = pick_exact(['symbol','ticker']) or pick_contains(['symbol','ticker','asset','name'])
    if time_col is None:
        time_col = pick_exact(['timestamp','datetime','date','time']) or pick_contains(['timestamp','datetime','date','time'])

    if price_col is None:
        price_col = (pick_exact(['priceusd','price','close','adjclose'])
                     or pick_contains(['priceusd','closeprice','lastprice','last','close','price']))
    if open_col is None:
        open_col = pick_exact(['open']) or pick_contains(['open'])
    if close_col is None:
        close_col = pick_exact(['close','adjclose']) or pick_contains(['close','closing'])

    if asset_col is None or time_col is None:
        raise ValueError(f"Missing key columns. Found asset={asset_col}, time={time_col}")

    d[time_col] = pd.to_datetime(d[time_col], errors='coerce')
    d = d.dropna(subset=[time_col]).sort_values([asset_col, time_col])

    def to_num(x):
        return (x.astype(str)
                 .str.replace(r'[^0-9.\-]', '', regex=True)
                 .replace({'': np.nan})
                 .astype(float))

    if price_col is not None:
        d[price_col] = to_num(d[price_col])
        d = d.dropna(subset=[price_col])
        d['ret_1h'] = d.groupby(asset_col, group_keys=False)[price_col].apply(lambda s: s.pct_change()*100.0)
    elif open_col is not None and close_col is not None:
        d[open_col], d[close_col] = to_num(d[open_col]), to_num(d[close_col])
        d = d.dropna(subset=[open_col, close_col])
        d['ret_1h'] = (d[close_col] - d[open_col]) / d[open_col] * 100.0
    else:
        raise ValueError("Provide a price column or both open & close columns.")

    d = d.dropna(subset=['ret_1h'])
    return d.rename(columns={asset_col:'symbol', time_col:'timestamp'})[['symbol','timestamp','ret_1h']]

# Build returns
crypto_ret = returns_from_frame(ccd_clean)
stock_ret  = returns_from_frame(sd)  # if this fails, override with your exact column names

# Examples if needed:
# stock_ret = returns_from_frame(sd, asset_col='Ticker', time_col='Date', price_col='Close')
# stock_ret = returns_from_frame(sd, asset_col='Ticker', time_col='Date', open_col='Open', close_col='Close')

crypto_ret['asset_class'] = 'Crypto'
stock_ret['asset_class']  = 'Stock'
rets = pd.concat([crypto_ret, stock_ret], ignore_index=True)

# Pick which assets to show
N = 4  # change as you like
top_assets = (rets.groupby('symbol').size()
              .sort_values(ascending=False)
              .head(N).index.tolist())
plot_df = rets[rets['symbol'].isin(top_assets)].copy()

# Build common bins
# Wider bins if stock returns are near 0; increase BIN_COUNT for more detail
BIN_COUNT = 80
ret_min = plot_df['ret_1h'].quantile(0.01)
ret_max = plot_df['ret_1h'].quantile(0.99)
if not np.isfinite(ret_min) or not np.isfinite(ret_max) or ret_min == ret_max:
    ret_min, ret_max = plot_df['ret_1h'].min(), plot_df['ret_1h'].max()
if ret_min == ret_max:  # all zeros
    ret_min, ret_max = -0.5, 0.5
bins = np.linspace(ret_min, ret_max, BIN_COUNT + 1)

# Render a BarChart per asset
charts = []
for sym in top_assets:
    vals = plot_df.loc[plot_df['symbol'] == sym, 'ret_1h'].to_numpy()
    if vals.size == 0:
        continue
    counts, bin_edges = np.histogram(vals, bins=bins)

    # Nicer category labels: show every ~5th bin to avoid clutter
    bar_data = []
    for i, count in enumerate(counts):
        if BIN_COUNT > 60 and i % 5 != 0:
            label = ""  # sparse labels for readability
        else:
            label = f"{bin_edges[i]:.2f}–{bin_edges[i+1]:.2f}"
        bar_data.append({"category": label, "value": int(count)})

    chart = lc.BarChart(
        vertical=True,
        theme=lc.Themes.Light,
        title=f'Hourly Price Change (%) - {sym}\n'
              f'X: Hourly return (%) bins   |   Y: Frequency',
        legend={'visible': False},
        html_text_rendering=True
    )
    chart.set_data(bar_data)
    chart.set_sorting('disabled')     # keep bin order
    chart.set_bars_color('cyan')
    charts.append(chart)

for c in charts:
    c.open()

# Chart 2A - Strip (Jittered Scatter) of Trading Volume by Asset (log10)
# Developed with AI assistance to demonstrate LightningChart Python

import lightningchart as lc
import re
import numpy as np
import pandas as pd

# License
with open("D:/HAMK/Internship/MyProjects/lc_license.txt", "r") as f:
     lc.set_license(f.read().strip())

try:
    ccd_clean
except NameError:
    ccd_clean = pd.read_csv("cryptocurrency.csv", encoding="latin1")
try:
    sd
except NameError:
    sd = pd.read_csv("stocks.csv", encoding="latin1")

# Helpers
def _norm(s):
    return re.sub(r'[^a-z0-9]', '', str(s).lower())

def _detect_col(df, exact=None, contains=None):
    exact = exact or []
    contains = contains or []
    cmap = {_norm(c): c for c in df.columns}
    keys = set(cmap.keys())
    for key in exact:
        if key in keys:
            return cmap[key]
    for k in keys:
        if any(sub in k for sub in contains):
            return cmap[k]
    return None

def build_volume_tidy(df, asset_label):
    """Return columns: symbol, volume (float), asset_class."""
    d = df.copy()
    sym_col = _detect_col(d, exact=['symbol','ticker'], contains=['symbol','ticker','name'])
    vol_col = (_detect_col(d, exact=['vol24h','totalvol','volume'],
                           contains=['vol24h','totalvol','volume'])
               or _detect_col(d, contains=['vol']))  # last resort
    if sym_col is None or vol_col is None:
        raise ValueError(f"Could not find symbol/volume in columns: {list(d.columns)}")

    # Coerce volume to numeric (strip commas, units)
    d[vol_col] = (d[vol_col].astype(str)
                  .str.replace(r'[^0-9.\-eE]', '', regex=True)
                  .replace({'': np.nan})
                  .astype(float))
    d = d.dropna(subset=[sym_col, vol_col])

    out = d[[sym_col, vol_col]].rename(columns={sym_col:'symbol', vol_col:'volume'})
    out['asset_class'] = asset_label
    return out

# Build tidy volumes
vol_crypto = build_volume_tidy(ccd_clean, 'Crypto')
vol_stocks = build_volume_tidy(sd, 'Stock')
vol = pd.concat([vol_crypto, vol_stocks], ignore_index=True)

# Focus on top-N assets by count for clarity
N = 8
top_assets = (vol.groupby('symbol').size()
              .sort_values(ascending=False).head(N).index.tolist())
plot_df = vol[vol['symbol'].isin(top_assets)].copy()

# Log-transform volume to compress scale differences
plot_df = plot_df[plot_df['volume'] > 0].copy()
plot_df['log10_volume'] = np.log10(plot_df['volume'])

# Map each symbol to an x-category with jitter
symbols = sorted(plot_df['symbol'].unique().tolist())
x_index = {s:i for i,s in enumerate(symbols)}
rng = np.random.default_rng(42)
plot_df['x'] = plot_df['symbol'].map(x_index).astype(float) + rng.uniform(-0.3, 0.3, size=len(plot_df))
plot_df['y'] = plot_df['log10_volume']

# Compute per-asset medians for reference lines
medians = plot_df.groupby('symbol')['y'].median()

# LightningChart rendering
chart = lc.ChartXY(theme=lc.Themes.Light,html_text_rendering=True,
                   title='Trading Volume by Asset - Strip (Jittered) Plot - log10 scale')

# Helper to add series (handles API name variations)
def add_points(ch):
    for fn in ('addPointSeries','add_point_series'):
        if hasattr(ch, fn): return getattr(ch, fn)()
    raise AttributeError("Point series adder not found on ChartXY.")

def add_line(ch):
    for fn in ('addLineSeries','add_line_series'):
        if hasattr(ch, fn): return getattr(ch, fn)()
    raise AttributeError("Line series adder not found on ChartXY.")

def add_data(series, arr2d):
    # try ndarray; fall back to list[dict] or list[tuple]
    try:
        series.add(arr2d); return
    except Exception:
        pass
    try:
        series.add([{'x': float(x), 'y': float(y)} for x,y in arr2d]); return
    except Exception:
        pass
    series.add([(float(x), float(y)) for x,y in arr2d])

def set_point_size(series, size=3.0):
    for fn in ('setPointSize','set_point_size'):
        if hasattr(series, fn):
            try: getattr(series, fn)(size)
            except Exception: pass

def set_stroke(series, thickness=2.0):
    for fn in ('setStrokeThickness','set_stroke_thickness'):
        if hasattr(series, fn):
            try: getattr(series, fn)(thickness)
            except Exception: pass

def set_name(series, name):
    for fn in ('setName','set_name','setLabel','set_label'):
        if hasattr(series, fn):
            try: getattr(series, fn)(name)
            except Exception: pass

# One point series per asset
for sym in symbols:
    s = add_points(chart)
    set_name(s, sym)
    set_point_size(s, 3.0)
    data = plot_df.loc[plot_df['symbol']==sym, ['x','y']].to_numpy()
    add_data(s, data)

# Median reference line per asset (short horizontal segment at x=category ±0.35)
for i, sym in enumerate(symbols):
    y = medians.loc[sym]
    x0, x1 = i-0.35, i+0.35
    seg = np.array([[x0, y],[x1, y]], dtype=float)
    l = add_line(chart)
    set_name(l, f'{sym} median')
    set_stroke(l, 2.5)
    add_data(l, seg)

# Nice viewing window
xmin, xmax = -0.8, len(symbols)-0.2
ymin, ymax = plot_df['y'].quantile(0.02), plot_df['y'].quantile(0.98)
if not np.isfinite(ymin) or not np.isfinite(ymax) or ymin==ymax:
    ymin, ymax = plot_df['y'].min(), plot_df['y'].max()
# Try to set intervals if your build exposes them (safe to ignore if missing)
for axis_fn, lo, hi in (('getDefaultAxisX', xmin, xmax), ('getDefaultAxisY', ymin, ymax)):
    if hasattr(chart, axis_fn):
        try:
            axis = getattr(chart, axis_fn)()
            if hasattr(axis, 'setInterval'):
                axis.setInterval(lo, hi)
        except Exception:
            pass


chart.open()

# Chart 2B - Box Plot of Trading Volume by Asset (log10)
# Developed with AI assistance to demonstrate LightningChart Python

import lightningchart as lc
import re
import numpy as np
import pandas as pd

# License
with open("D:/HAMK/Internship/MyProjects/lc_license.txt", "r") as f:
     lc.set_license(f.read().strip())

# Ensure dataframes exist
try: ccd_clean
except NameError: ccd_clean = pd.read_csv("cryptocurrency.csv", encoding="latin1")
try: sd
except NameError: sd = pd.read_csv("stocks.csv", encoding="latin1")

# Helpers
def _norm(s): return re.sub(r'[^a-z0-9]', '', str(s).lower())
def _detect_col(df, exact=None, contains=None):
    exact, contains = exact or [], contains or []
    cmap = {_norm(c): c for c in df.columns}; keys = set(cmap.keys())
    for k in exact:
        if k in keys: return cmap[k]
    for kn in keys:
        if any(sub in kn for sub in contains): return cmap[kn]
    return None

def build_volume_tidy(df, asset_label):
    d = df.copy()
    sym_col = _detect_col(d, exact=['symbol','ticker'], contains=['symbol','ticker','name'])
    vol_col = (_detect_col(d, exact=['vol24h','totalvol','volume'],
                           contains=['vol24h','totalvol','volume'])
               or _detect_col(d, contains=['vol']))
    if sym_col is None or vol_col is None:
        raise ValueError(f"Could not find symbol/volume in: {list(d.columns)}")
    d[vol_col] = (d[vol_col].astype(str)
                  .str.replace(r'[^0-9.\-eE]', '', regex=True)
                  .replace({'': np.nan}).astype(float))
    d = d.dropna(subset=[sym_col, vol_col])
    out = d[[sym_col, vol_col]].rename(columns={sym_col:'symbol', vol_col:'volume'})
    out['asset_class'] = asset_label
    return out

# Assemble tidy volume data
vol = pd.concat([
    build_volume_tidy(ccd_clean, 'Crypto'),
    build_volume_tidy(sd, 'Stock')
], ignore_index=True)

# Keep only positive volumes and compute log10
vol = vol[vol['volume'] > 0].copy()
vol['log10_volume'] = np.log10(vol['volume'])

# Choose top-N assets by row count (keeps charts readable)
N = 10
symbols = (vol.groupby('symbol').size()
           .sort_values(ascending=False).head(N).index.tolist())

# Build category->data mapping (log10 volumes)
category_data = {sym: vol.loc[vol['symbol']==sym, 'log10_volume'].to_numpy()
                 for sym in symbols}

# Build Box Plot
chart = lc.ChartXY(theme=lc.Themes.Light,
                   title='Box Plot - Trading Volume by Asset (Y = log10(volume))',
                   html_text_rendering=True)

# Add box series (handle method naming differences)
box_series = chart.add_box_series() if hasattr(chart, 'add_box_series') else chart.addBoxSeries()

dataset = []
x_out, y_out = [], []

for i, sym in enumerate(symbols):
    data = category_data[sym]
    if data.size == 0:
        continue

    start = (i * 2) + 1
    end   = start + 1

    q1 = float(np.percentile(data, 25))
    q3 = float(np.percentile(data, 75))
    med = float(np.median(data))
    iqr = q3 - q1
    lower_bound = q1 - 1.5 * iqr
    upper_bound = q3 + 1.5 * iqr

    non_out = data[(data >= lower_bound) & (data <= upper_bound)]
    if non_out.size == 0:
        # fallback if everything looks like an outlier
        non_out = data

    lower_ext = float(np.min(non_out))
    upper_ext = float(np.max(non_out))

    dataset.append({
        'start': start,
        'end': end,
        'lowerQuartile': q1,
        'upperQuartile': q3,
        'median': med,
        'lowerExtreme': lower_ext,
        'upperExtreme': upper_ext,
    })

    # collect outliers
    outliers = data[(data < lower_bound) | (data > upper_bound)]
    if outliers.size:
        x_out.extend([start + 0.5] * len(outliers))
        y_out.extend(outliers.tolist())

# Push all boxes at once
box_series.add_multiple(dataset)

# Add outliers (if any)
if len(y_out):
    pt_series = (chart.add_point_series(sizes=True, rotations=True, lookup_values=True)
                 if hasattr(chart, 'add_point_series') else chart.addPointSeries(sizes=True, rotations=True, lookup_values=True))
    pt_series.set_point_color('red')
    pt_series.append_samples(x_values=x_out, y_values=y_out, sizes=[9]*len(y_out))

# Optional: show asset names on X axis using categories (if supported)
try:
    axX = chart.getDefaultAxisX()
    if hasattr(lc, 'AxisTickStrategies'):
        axX.setTickStrategy(lc.AxisTickStrategies.Category)
        centers = [(i*2)+1.5 for i in range(len(symbols))]
        axX.setCategories([lc.Category(label=sym, value=centers[i]) for i, sym in enumerate(symbols)])
except Exception:
    pass

chart.open()

# Chart 3A - Scatter Plot of Open vs Close Prices (colored by asset)
# Developed with AI assistance to demonstrate LightningChart Python

import lightningchart as lc
import re
import numpy as np
import pandas as pd

# License
with open("D:/HAMK/Internship/MyProjects/lc_license.txt", "r") as f:
     lc.set_license(f.read().strip())

# Ensure dataframes exist
try:
    ccd_clean
except NameError:
    ccd_clean = pd.read_csv("cryptocurrency.csv", encoding="latin1")
try:
    sd
except NameError:
    sd = pd.read_csv("stocks.csv", encoding="latin1")

# Helpers
def _norm(s): return re.sub(r'[^a-z0-9]', '', str(s).lower())

def _detect(df, exact=None, contains=None):
    exact, contains = exact or [], contains or []
    cmap = {_norm(c): c for c in df.columns}; keys = set(cmap.keys())
    for k in exact:
        if k in keys: return next(c for c in df.columns if _norm(c)==k)
    for col in df.columns:
        if any(sub in _norm(col) for sub in contains or []):
            return col
    return None

def _to_num(s):
    return (s.astype(str)
             .str.replace(r'[^0-9.\-eE]', '', regex=True)
             .replace({'': np.nan})
             .astype(float))

def open_close_from_df(df, asset_label=None,
                       asset_col=None, time_col=None,
                       open_col=None, close_col=None, price_col=None):
    """Return tidy [symbol, timestamp, open, close, asset_class].
       If only a single price column exists, uses prev price as 'open' (close-to-close)."""
    d = df.copy()

    # Detect columns
    asset_col = asset_col or _detect(d, exact=['symbol','ticker'], contains=['symbol','ticker','name'])
    time_col  = time_col  or _detect(d, exact=['timestamp','datetime','date','time'],
                                     contains=['timestamp','datetime','date','time'])
    if open_col is None:
        open_col = _detect(d, exact=['open'])
    if close_col is None:
        close_col = _detect(d, exact=['close','adjclose'], contains=['close'])
    if price_col is None:
        price_col = _detect(d, exact=['priceusd','price'], contains=['priceusd','last','price'])

    if asset_col is None or time_col is None:
        raise ValueError(f"Missing key columns. Found asset={asset_col}, time={time_col}")

    # Parse + sort
    d[time_col] = pd.to_datetime(d[time_col], errors='coerce')
    d = d.dropna(subset=[time_col]).sort_values([asset_col, time_col])

    if close_col is not None and open_col is not None:
        d[open_col]  = _to_num(d[open_col])
        d[close_col] = _to_num(d[close_col])
        out = d.dropna(subset=[open_col, close_col]).copy()
        out = out.rename(columns={asset_col:'symbol', time_col:'timestamp',
                                  open_col:'open', close_col:'close'})
    else:
        # Fallback: single price -> open = previous close within each asset
        pcol = close_col or price_col
        if pcol is None:
            raise ValueError("Could not find Open/Close/Price columns.")
        d[pcol] = _to_num(d[pcol])
        d = d.dropna(subset=[pcol]).copy()
        d['open']  = d.groupby(asset_col, group_keys=False)[pcol].shift(1)
        d['close'] = d[pcol]
        out = d.dropna(subset=['open','close']).rename(
            columns={asset_col:'symbol', time_col:'timestamp'}
        )[['symbol','timestamp','open','close']]

    if asset_label is not None:
        out['asset_class'] = asset_label
    return out

# Build tidy open/close pairs
oc_crypto = open_close_from_df(ccd_clean, asset_label='Crypto')
oc_stocks = open_close_from_df(sd,        asset_label='Stock')
oc = pd.concat([oc_crypto, oc_stocks], ignore_index=True)

# Pick top-N assets by sample count for legible plot
N = 10
top_assets = (oc.groupby('symbol').size()
                .sort_values(ascending=False).head(N).index.tolist())
plot_df = oc[oc['symbol'].isin(top_assets)].copy()

# LightningChart scatter
chart = lc.ChartXY(theme=lc.Themes.White,
                   title='Open vs Close Prices - Colored by Asset',
                   html_text_rendering=True)

# Helper functions (handle API naming differences)
def add_points(ch):
    for fn in ('addPointSeries','add_point_series'):
        if hasattr(ch, fn): return getattr(ch, fn)()
    raise AttributeError("Point series adder not found.")

def add_line(ch):
    for fn in ('addLineSeries','add_line_series'):
        if hasattr(ch, fn): return getattr(ch, fn)()
    raise AttributeError("Line series adder not found.")

def add_xy(series, arr):
    for payload in (arr,
                    [{'x': float(x), 'y': float(y)} for x,y in arr],
                    [(float(x), float(y)) for x,y in arr]):
        try: series.add(payload); return
        except Exception: pass

def set_name(s, name):
    for fn in ('setName','set_name','setLabel','set_label'):
        if hasattr(s, fn):
            try: getattr(s, fn)(name)
            except Exception: pass

def set_point_size(s, size):
    for fn in ('setPointSize','set_point_size'):
        if hasattr(s, fn):
            try: getattr(s, fn)(size)
            except Exception: pass

# Add a y=x reference line (sessions finishing flat)
xy_min = float(min(plot_df[['open','close']].min()))
xy_max = float(max(plot_df[['open','close']].max()))
ref = add_line(chart)
add_xy(ref, np.array([[xy_min, xy_min], [xy_max, xy_max]], dtype=float))
try: ref.setStrokeThickness(1.5)
except Exception: pass
set_name(ref, 'y = x')

# Add a point series per asset (colored by asset automatically by LC theme)
for sym in top_assets:
    s = add_points(chart)
    set_name(s, sym)
    set_point_size(s, 2.2)
    pts = plot_df.loc[plot_df['symbol']==sym, ['open','close']].to_numpy(dtype=float)
    add_xy(s, pts)

# Axes titles (safe if supported)
try: chart.getDefaultAxisX().setTitle('Open Price')
except Exception: pass
try: chart.getDefaultAxisY().setTitle('Close Price')
except Exception: pass

# Make the view square-ish to read the y=x line fairly
try:
    # Pad a bit around range
    pad = 0.03 * (xy_max - xy_min if np.isfinite(xy_max-xy_min) else 1.0)
    x0, x1 = xy_min - pad, xy_max + pad
    y0, y1 = x0, x1
    axX, axY = chart.getDefaultAxisX(), chart.getDefaultAxisY()
    if hasattr(axX,'setInterval'): axX.setInterval(x0, x1)
    if hasattr(axY,'setInterval'): axY.setInterval(y0, y1)
except Exception:
    pass


chart.open()

# Chart 3B - Spider Chart of Hour-of-Day Volatility for 4 assets
# Metric: mean absolute return (%) per hour-of-day
# Axes: every 3 hours (0, 3, …, 21). Values normalized to 0–100 across all assets/hours.
# Developed with AI assistance to demonstrate LightningChart Python

import lightningchart as lc
import numpy as np
import pandas as pd
import re

# License
with open("D:/HAMK/Internship/MyProjects/lc_license.txt", "r") as f:
    lc.set_license(f.read().strip())

try:
    ccd_clean
except NameError:
    ccd_clean = pd.read_csv("cryptocurrency.csv", encoding="latin1")
try:
    sd
except NameError:
    sd = pd.read_csv("stocks.csv", encoding="latin1")

# Helpers
def _norm(s): return re.sub(r'[^a-z0-9]', '', str(s).lower())

def _detect(df, exact=(), contains=()):
    if df is None or df.empty: return None
    cmap = {_norm(c): c for c in df.columns}
    keys = set(cmap.keys())
    for k in exact or ():
        if k in keys: return cmap[k]
    for c in df.columns:
        if any(sub in _norm(c) for sub in (contains or ())): return c
    return None

def _to_num(s):
    return pd.to_numeric(
        s.astype(str).str.replace(r'[^0-9.\-eE]', '', regex=True).replace({'': np.nan}),
        errors='coerce'
    )

def hourly_abs_returns(df, asset_label=None,
                       asset_col=None, time_col=None,
                       price_col=None, open_col=None, close_col=None):
    """Tidy DF: symbol, timestamp, hour, abs_ret_pct (+ asset_class). Returns empty DF if not derivable."""
    if df is None or df.empty:
        return pd.DataFrame(columns=['symbol','timestamp','hour','abs_ret_pct','asset_class'])

    d = df.copy()
    asset_col = asset_col or _detect(d, exact=('symbol','ticker'), contains=('symbol','ticker','name','asset'))
    time_col  = time_col  or _detect(d, exact=('timestamp','datetime','date','time'),
                                     contains=('timestamp','datetime','date','time'))
    if price_col is None:
        price_col = _detect(d, exact=('priceusd','price','close','adjclose'),
                               contains=('priceusd','price','last','close'))
    if open_col is None:
        open_col = _detect(d, exact=('open',), contains=('open',))
    if close_col is None:
        close_col = _detect(d, exact=('close','adjclose'), contains=('close',))

    if asset_col is None or time_col is None:
        return pd.DataFrame(columns=['symbol','timestamp','hour','abs_ret_pct','asset_class'])

    d[time_col] = pd.to_datetime(d[time_col], errors='coerce')
    d = d.dropna(subset=[time_col]).sort_values([asset_col, time_col])

    if open_col is not None and close_col is not None:
        d[open_col]  = _to_num(d[open_col])
        d[close_col] = _to_num(d[close_col])
        d = d.dropna(subset=[open_col, close_col])
        if d.empty:
            return pd.DataFrame(columns=['symbol','timestamp','hour','abs_ret_pct','asset_class'])
        ret_pct = (d[close_col] - d[open_col]) / d[open_col] * 100.0
    elif price_col is not None:
        d[price_col] = _to_num(d[price_col])
        d = d.dropna(subset=[price_col])
        if d.empty:
            return pd.DataFrame(columns=['symbol','timestamp','hour','abs_ret_pct','asset_class'])
        ret_pct = d.groupby(asset_col, group_keys=False)[price_col].pct_change() * 100.0
    else:
        return pd.DataFrame(columns=['symbol','timestamp','hour','abs_ret_pct','asset_class'])

    out = pd.DataFrame({
        'symbol': d[asset_col].values,
        'timestamp': d[time_col].values,
        'abs_ret_pct': np.abs(ret_pct.values)
    }).dropna(subset=['abs_ret_pct'])

    if out.empty:
        return pd.DataFrame(columns=['symbol','timestamp','hour','abs_ret_pct','asset_class'])

    out['hour'] = pd.to_datetime(out['timestamp']).dt.hour
    if asset_label is not None:
        out['asset_class'] = asset_label
    return out[['symbol','timestamp','hour','abs_ret_pct','asset_class']]

# Build data
ar_crypto = hourly_abs_returns(ccd_clean, 'Crypto')
ar_stocks = hourly_abs_returns(sd,        'Stock')
ar = pd.concat([ar_crypto, ar_stocks], ignore_index=True)

if ar.empty:
    raise RuntimeError("Could not compute hourly returns from the provided datasets.")

# Pick 4 assets by sample count
N = 4
top_assets = (ar.groupby('symbol').size().sort_values(ascending=False).head(N).index.tolist())
plot = ar[ar['symbol'].isin(top_assets)].copy()

# Mean |return| % per hour-of-day per asset
hourly = (plot.groupby(['symbol','hour'])['abs_ret_pct']
               .mean()
               .reset_index())

# Spider axes: every 3 hours to keep it readable (8 axes)
hours = list(range(0, 24, 3))  # 0,3,6,9,12,15,18,21
categories = [f'{h:02d}h' for h in hours]

# Global normalization for comparability → 0..100
r_max = hourly.loc[hourly['hour'].isin(hours), 'abs_ret_pct'].max()
if not np.isfinite(r_max) or r_max <= 0:
    r_max = 1.0

def points_for_symbol(sym):
    vals = []
    for h in hours:
        v = hourly.loc[(hourly['symbol']==sym) & (hourly['hour']==h), 'abs_ret_pct'].mean()
        if not np.isfinite(v): v = 0.0
        vals.append(float(v) / r_max * 100.0)  # scale to 0..100
    return [{'axis': cat, 'value': val} for cat, val in zip(categories, vals)]

# Spider Chart
chart = lc.SpiderChart(
    theme=lc.Themes.Dark,
    title='Hour-of-Day Volatility - Spider (radius = relative mean |return|, 0..100)',
    html_text_rendering=True
)

# Set the axes (categories) explicitly if the API supports it
if hasattr(chart, 'set_categories'):
    chart.set_categories(categories)

# Add 4 series (one per asset)
for sym in top_assets:
    series = chart.add_series()
    series.set_name(sym) if hasattr(series,'set_name') else None
    series.add_points(points_for_symbol(sym))

chart.open()

# Chart 4A - Treemap of Market Capitalization (or Proxy) by Class --> Asset
# Radius = mean absolute return (%) per hour-of-day, normalized (0..1)
# Developed with AI assistance to demonstrate LightningChart Python

import lightningchart as lc
import numpy as np
import pandas as pd
import re

# License
with open("D:/HAMK/Internship/MyProjects/lc_license.txt", "r") as f:
     lc.set_license(f.read().strip())

try: ccd_clean
except NameError: ccd_clean = pd.read_csv("cryptocurrency.csv", encoding="latin1")
try: sd
except NameError: sd = pd.read_csv("stocks.csv", encoding="latin1")

def _norm(s): return re.sub(r'[^a-z0-9]', '', str(s).lower())

def _pick_col(df, *, exact=(), contains=(), exclude_contains=()):
    """Pick first column by exact name or substring; avoid excluded substrings."""
    normed = {_norm(c): c for c in df.columns}
    keys = set(normed.keys())

    def ok(name):
        n = _norm(name)
        return not any(ex in n for ex in exclude_contains)

    for k in exact:
        if k in keys and ok(normed[k]):
            return normed[k]
    for c in df.columns:
        cn = _norm(c)
        if any(sub in cn for sub in contains) and ok(c):
            return c
    return None

def _num(s):
    # robust numeric coercion
    x = (s.astype(str)
          .str.replace(r'[^0-9.\-eE]', '', regex=True)
          .replace({'': np.nan}))
    return pd.to_numeric(x, errors='coerce')

def _first(*vals):
    for v in vals:
        if v is not None: return v
    return None

def summarize_assets(df: pd.DataFrame, asset_label: str):
    d = df.copy()

    asset_col = _first(
        _pick_col(d, exact=('symbol','ticker','name','asset'),
                     contains=('symbol','ticker','name','asset','security','company'))
    )

    mcap_col = _first(
        _pick_col(d, exact=('marketcap','market_cap','marketcapitalization','marketcapitalisation'),
                     contains=('marketcap','marketcapital','mktcap','mktcapital'),
                     exclude_contains=('time','date','stamp'))
    )

    close_col = _first(
        _pick_col(d, exact=('close','adjclose','closeprice','price','last','closeusd','closeus'),
                     contains=('close','adjclose','last','price'),
                     exclude_contains=('time','date','stamp'))
    )

    open_col = _first(
        _pick_col(d, exact=('open','openprice'),
                     contains=('open',),
                     exclude_contains=('time','date','stamp'))
    )

    vol_col = _first(
        _pick_col(d, exact=('volume','vol','volumeusd','totalvolume','volumeto','sharestraded','turnover'),
                     contains=('volume','vol','turnover','shares'),
                     exclude_contains=('time','date','stamp'))
    )

    if asset_col is None:
        raise ValueError(f"[{asset_label}] No symbol/ticker column found in: {list(d.columns)}")

    for c in (mcap_col, close_col, open_col, vol_col):
        if c is not None:
            d[c] = _num(d[c])

    candidates = []

    if mcap_col is not None:
        mc = d[[asset_col, mcap_col]].dropna()
        if not mc.empty and mc[mcap_col].gt(0).any():
            g = (mc.groupby(asset_col, as_index=False)[mcap_col].median()
                   .rename(columns={mcap_col: 'value'}))
            g['source'] = 'market_cap (median)'
            candidates.append(g)

    if close_col is not None and vol_col is not None:
        d['__liq__'] = d[close_col] * d[vol_col]
        liq = d[[asset_col, '__liq__']].replace([np.inf,-np.inf], np.nan).dropna()
        if not liq.empty and liq['__liq__'].gt(0).any():
            g = (liq.groupby(asset_col, as_index=False)['__liq__'].median()
                   .rename(columns={'__liq__': 'value'}))
            g['source'] = 'median(close×volume)'
            candidates.append(g)

    price_like = close_col if close_col is not None else open_col
    if price_like is not None:
        p = d[[asset_col, price_like]].dropna()
        if not p.empty and p[price_like].gt(0).any():
            g = (p.groupby(asset_col, as_index=False)[price_like].median()
                   .rename(columns={price_like: 'value'}))
            g['source'] = f'median({price_like}) price proxy'
            candidates.append(g)

    if not candidates:
        g = (d.groupby(asset_col, as_index=False)[asset_col].size()
               .rename(columns={'size': 'value'}))
        g['source'] = 'row_count proxy'
        candidates.append(g)

    out = candidates[0].copy()
    out['asset_class'] = asset_label
    out.rename(columns={asset_col: 'symbol'}, inplace=True)
    out = out[out['value'].replace([np.inf,-np.inf], np.nan).fillna(0) > 0]

    return out.reset_index(drop=True)

# build summaries
crypto = summarize_assets(ccd_clean, 'Crypto')
stocks = summarize_assets(sd,        'Stock')
summary = pd.concat([crypto, stocks], ignore_index=True)

TOP_N = 30
summary = (summary.sort_values('value', ascending=False)
                  .groupby('asset_class', group_keys=False)
                  .head(TOP_N)
                  .reset_index(drop=True))

nodes = []
for grp, g in summary.groupby('asset_class'):
    children = [{'name': sym, 'value': float(val)} for sym, val in zip(g['symbol'], g['value'])]
    src = g['source'].mode().iat[0] if 'source' in g and not g['source'].empty else ''
    nodes.append({'name': f"{grp} [{src}]", 'children': children})

# Treemap (with class-name fallback)
treemap = None
for cls in ('TreeMapChart','TreemapChart','TreeMap'):
    if hasattr(lc, cls):
        treemap = getattr(lc, cls)(theme=lc.Themes.Light,
                                   title=('Market Capitalization / Proxy - Crypto vs Stocks\n'
                                          '(priority: mcap --> median(close×volume) --> median(price) --> row_count)'),
                                   html_text_rendering=True)
        break
if treemap is None:
    raise RuntimeError("Treemap chart class not found in lightningchart.")

# Coloring (safe)
vmin, vmax = float(summary['value'].min()), float(summary['value'].max())
try:
    if not np.isfinite(vmin) or not np.isfinite(vmax) or vmin == vmax:
        treemap.set_node_coloring(steps=[{'value': 0, 'color': '#8ecae6'},
                                         {'value': 1, 'color': '#ffb703'}])
    else:
        treemap.set_node_coloring(steps=[
            {'value': vmin,          'color': '#8ecae6', 'label':'Min'},
            {'value': (vmin+vmax)/2, 'color': '#ffb703', 'label':' '},
            {'value': vmax,          'color': '#fb8500', 'label':'Max'},
        ])
except Exception:
    pass

for fn in ('set_data','setData'):
    if hasattr(treemap, fn):
        getattr(treemap, fn)(nodes); break

treemap.open()

# Chart 4B - Stacked Bar of Class totals split by Top-K assets (+ Others)
# Auto unit scaling (K/M/B/T) for very large values
# Developed with AI assistance to demonstrate LightningChart Python

import lightningchart as lc
import numpy as np
import pandas as pd
import re

# License
with open("D:/HAMK/Internship/MyProjects/lc_license.txt", "r") as f:
    lc.set_license(f.read().strip())

# Ensure dataframes exist
try: ccd_clean
except NameError: ccd_clean = pd.read_csv("cryptocurrency.csv", encoding="latin1")
try: sd
except NameError: sd = pd.read_csv("stocks.csv", encoding="latin1")

# Helpers
def _norm(s): return re.sub(r'[^a-z0-9]', '', str(s).lower())
def _pick_col(df, *, exact=(), contains=(), exclude_contains=()):
    normed = {_norm(c): c for c in df.columns}; keys = set(normed.keys())
    def ok(name): n = _norm(name); return not any(ex in n for ex in exclude_contains)
    for k in exact:
        if k in keys and ok(normed[k]): return normed[k]
    for c in df.columns:
        cn = _norm(c)
        if any(sub in cn for sub in contains) and ok(c): return c
    return None
def _num(s):
    x = (s.astype(str).str.replace(r'[^0-9.\-eE]', '', regex=True).replace({'': np.nan}))
    return pd.to_numeric(x, errors='coerce')
def _first(*vals):
    for v in vals:
        if v is not None: return v
    return None

def summarize_assets(df: pd.DataFrame, asset_label: str):
    d = df.copy()
    asset_col = _first(_pick_col(d, exact=('symbol','ticker','name','asset'),
                                 contains=('symbol','ticker','name','asset','security','company')))
    mcap_col = _first(_pick_col(d, exact=('marketcap','market_cap','marketcapitalization','marketcapitalisation'),
                                 contains=('marketcap','marketcapital','mktcap','mktcapital'),
                                 exclude_contains=('time','date','stamp')))
    close_col = _first(_pick_col(d, exact=('close','adjclose','closeprice','price','last','closeusd','closeus'),
                                 contains=('close','adjclose','last','price'),
                                 exclude_contains=('time','date','stamp')))
    open_col  = _first(_pick_col(d, exact=('open','openprice'), contains=('open',),
                                 exclude_contains=('time','date','stamp')))
    vol_col   = _first(_pick_col(d, exact=('volume','vol','volumeusd','totalvolume','volumeto','sharestraded','turnover'),
                                 contains=('volume','vol','turnover','shares'),
                                 exclude_contains=('time','date','stamp')))
    if asset_col is None:
        raise ValueError(f"[{asset_label}] No symbol/ticker column found.")

    for c in (mcap_col, close_col, open_col, vol_col):
        if c is not None: d[c] = _num(d[c])

    candidates = []
    if mcap_col is not None:
        mc = d[[asset_col, mcap_col]].dropna()
        if not mc.empty and mc[mcap_col].gt(0).any():
            g = (mc.groupby(asset_col, as_index=False)[mcap_col].median()
                   .rename(columns={mcap_col:'value'}))
            g['source'] = 'market_cap (median)'; candidates.append(g)

    if close_col is not None and vol_col is not None:
        d['__liq__'] = d[close_col] * d[vol_col]
        liq = d[[asset_col,'__liq__']].replace([np.inf,-np.inf], np.nan).dropna()
        if not liq.empty and liq['__liq__'].gt(0).any():
            g = (liq.groupby(asset_col, as_index=False)['__liq__'].median()
                   .rename(columns={'__liq__':'value'}))
            g['source'] = 'median(close×volume)'; candidates.append(g)

    price_like = close_col if close_col is not None else open_col
    if price_like is not None:
        p = d[[asset_col, price_like]].dropna()
        if not p.empty and p[price_like].gt(0).any():
            g = (p.groupby(asset_col, as_index=False)[price_like].median()
                   .rename(columns={price_like:'value'}))
            g['source'] = f'median({price_like}) price proxy'; candidates.append(g)

    if not candidates:
        g = (d.groupby(asset_col, as_index=False)[asset_col].size()
               .rename(columns={'size':'value'}))
        g['source'] = 'row_count proxy'; candidates.append(g)

    out = candidates[0].copy()
    out['asset_class'] = asset_label
    out.rename(columns={asset_col:'symbol'}, inplace=True)
    out = out[out['value'].replace([np.inf,-np.inf], np.nan).fillna(0) > 0]
    return out.reset_index(drop=True)

# Build summary
crypto = summarize_assets(ccd_clean, 'Crypto')
stocks = summarize_assets(sd,        'Stock')
summary = pd.concat([crypto, stocks], ignore_index=True)

TOP_K = 5
categories = ['Crypto', 'Stock']

def topk_plus_others(df_class, label_others):
    dfc = df_class.sort_values('value', ascending=False)
    top = dfc.head(TOP_K)[['symbol','value']]
    total = dfc['value'].sum()
    others_val = float(total - top['value'].sum())
    out = list(zip(top['symbol'].tolist(), top['value'].astype(float).tolist()))
    if others_val > 0:
        out.append((label_others, others_val))
    return out, total

crypto_list, crypto_total = topk_plus_others(summary[summary['asset_class']=='Crypto'], 'Others (Crypto)')
stock_list,  stock_total  = topk_plus_others(summary[summary['asset_class']=='Stock'],  'Others (Stock)')

# Union of subcategories (so stacks align)
subcats = [name for name, _ in crypto_list] + [name for name, _ in stock_list]
subcats = list(dict.fromkeys(subcats))
val_map_crypto = dict(crypto_list)
val_map_stock  = dict(stock_list)

# Auto unit scaling
max_val = max(sum(v for _, v in crypto_list), sum(v for _, v in stock_list))
scales = [(1e12, 'Trillions'), (1e9, 'Billions'), (1e6, 'Millions'), (1e3, 'Thousands'), (1.0, '')]
scale, unit = next(((s, u) for s, u in scales if max_val / s >= 1.0), (1.0, ''))

scaled_stack = []
for name in subcats:
    scaled_stack.append({
        'subCategory': name,
        'values': [
            float(val_map_crypto.get(name, 0.0)) / scale,
            float(val_map_stock.get(name, 0.0))  / scale,
        ]
    })

# Render
title = f"Stacked Bar - Class Totals split by Top {TOP_K} Assets (+ Others)"
if unit:
    title += f"  [Values in {unit}]"

chart = lc.BarChart(
    vertical=True,
    theme=lc.Themes.Light,
    title=title,
    html_text_rendering=True,
    legend={'visible': True}
)

# Keep category order
for fn in ('set_sorting','setSorting'):
    if hasattr(chart, fn):
        getattr(chart, fn)('disabled'); break

# Push data (scaled)
for fn in ('set_data_stacked','setDataStacked'):
    if hasattr(chart, fn):
        getattr(chart, fn)(categories, scaled_stack); break

# Cosmetics
try: chart.set_bars_padding(0.15)
except Exception: pass

chart.open()

# Chart 5 - Side-by-Side Correlation Heatmaps of Crypto vs Stocks
# Developed with AI assistance to demonstrate LightningChart Python

import lightningchart as lc
import numpy as np
import pandas as pd
import re

# License
with open("D:/HAMK/Internship/MyProjects/lc_license.txt", "r") as f:
     lc.set_license(f.read().strip())

try: ccd_clean
except NameError: ccd_clean = pd.read_csv("cryptocurrency.csv", encoding="latin1")
try: sd
except NameError: sd = pd.read_csv("stocks.csv", encoding="latin1")

# helpers
def _norm(s): return re.sub(r'[^a-z0-9]', '', str(s).lower())

def _pick(df, *, exact=(), contains=()):
    m = {_norm(c): c for c in df.columns}
    for k in exact:
        if k in m:  # exact normalized key found
            # map back to original
            for c in df.columns:
                if _norm(c) == k: return c
    for c in df.columns:
        n = _norm(c)
        if any(sub in n for sub in contains): return c
    return None

def _to_num(s):
    x = (s.astype(str).str.replace(r'[^0-9.\-eE]', '', regex=True)
                  .replace({'': np.nan}))
    return pd.to_numeric(x, errors='coerce')

def _crypto_vars(df):
    """Return DataFrame with columns price, volume, high, low for crypto (with proxies if needed)."""
    d = df.copy()

    price_col  = (_pick(d, exact=('priceusd','price'), contains=('priceusd','price','last')) or
                  _pick(d, exact=('close','adjclose'), contains=('close',)))
    volume_col = (_pick(d, exact=('vol24h','totalvol','volume'),
                        contains=('vol24h','totalvol','volume','volumeto','turnover')))
    high_col   = _pick(d, exact=('high',), contains=('high',))
    low_col    = _pick(d, exact=('low',),  contains=('low',))
    chg_col    = _pick(d, exact=('chg24h','chg_24h','change24h'),
                        contains=('chg24','24h','pct','percent','change'))

    out = pd.DataFrame()

    if price_col is not None:
        price = _to_num(d[price_col])
        out['price'] = price

        # If no high/low, synthesize symmetric proxies from price & 24h change (bounded)
        if high_col is None or low_col is None:
            if chg_col is not None:
                dpct = _to_num(d[chg_col]).clip(-50, 50).abs().fillna(0.0) / 100.0
                # Make the synthetic band modest to avoid degenerate correlations
                band = (0.5 * dpct).fillna(0.0)
                out['high'] = price * (1.0 + band)
                out['low']  = price * (1.0 - band)
        if high_col is not None:
            out['high'] = _to_num(d[high_col])
        if low_col is not None:
            out['low']  = _to_num(d[low_col])

    if volume_col is not None:
        out['volume'] = _to_num(d[volume_col])

    return out.dropna()

def _stock_vars(df):
    """Return DataFrame with columns price, volume, high, low for stocks."""
    d = df.copy()
    open_col   = _pick(d, exact=('open','openprice'), contains=('open',))
    close_col  = (_pick(d, exact=('close','adjclose'), contains=('close',)) or
                  _pick(d, exact=('price',), contains=('price',)))
    high_col   = _pick(d, exact=('high','highprice'), contains=('high',))
    low_col    = _pick(d, exact=('low','lowprice'), contains=('low',))
    volume_col = _pick(d, exact=('volume',), contains=('volume','turnover','sharestraded'))

    out = pd.DataFrame()
    if close_col is not None: out['price']  = _to_num(d[close_col])
    elif open_col is not None: out['price'] = _to_num(d[open_col])
    if volume_col is not None: out['volume'] = _to_num(d[volume_col])
    if high_col is not None:   out['high']   = _to_num(d[high_col])
    if low_col is not None:    out['low']    = _to_num(d[low_col])
    return out.dropna()

def _corr4(df):
    """Build 4×4 corr matrix in order [price, volume, high, low]. Missing entries filled sensibly."""
    labels = ['price','volume','high','low']
    if df.empty:
        M = np.zeros((4,4), dtype=float)
        np.fill_diagonal(M, 1.0)
        return M, labels

    # retain available columns in correct order
    cols = [c for c in labels if c in df.columns]
    sub = df[cols].dropna()
    if len(sub) < 2:
        M = np.zeros((4,4), dtype=float)
        np.fill_diagonal(M, 1.0)
        return M, labels

    c = sub.corr().to_dict()
    M = np.zeros((4,4), dtype=float)
    for i, a in enumerate(labels):
        for j, b in enumerate(labels):
            if a in c and b in c[a] and pd.notna(c[a][b]):
                M[i,j] = c[a][b]
            elif a == b:
                M[i,j] = 1.0
            else:
                M[i,j] = 0.0
    return M, labels

# Build matrices
crypto_df = _crypto_vars(ccd_clean)
stock_df  = _stock_vars(sd)
M_crypto, labels = _corr4(crypto_df)
M_stock,  _      = _corr4(stock_df)

# render two heatmaps
chart = lc.ChartXY(
    theme=lc.Themes.Light,
    title='Correlation Heatmaps - Crypto vs Stocks (Price, Volume, High, Low)',
    html_text_rendering=True
)

def add_heatmap(ch, cols, rows):
    for fn in ('add_heatmap_grid_series','addHeatmapGridSeries'):
        if hasattr(ch, fn):
            return getattr(ch, fn)(columns=cols, rows=rows)
    raise AttributeError("No heatmap grid series method found.")

def apply_palette(series):
    palette = [
        {'value': -1.0, 'color': '#313695'},
        {'value': -0.5, 'color': '#74add1'},
        {'value':  0.0, 'color': '#ffffbf'},
        {'value':  0.5, 'color': '#f46d43'},
        {'value':  1.0, 'color': '#a50026'},
    ]
    series.set_palette_coloring(steps=palette, look_up_property='value', interpolate=True)

# Crypto (left)
h1 = add_heatmap(chart, 4, 4)
h1.set_start(x=0.0, y=0.0)
h1.set_end(  x=4.2, y=4.0)
h1.set_step(x=1, y=1)
h1.set_intensity_interpolation(True)
h1.invalidate_intensity_values(M_crypto.tolist())
h1.hide_wireframe()
apply_palette(h1)

# Stocks (right)
h2 = add_heatmap(chart, 4, 4)
h2.set_start(x=4.8, y=0.0)
h2.set_end(  x=9.0, y=4.0)
h2.set_step(x=1, y=1)
h2.set_intensity_interpolation(True)
h2.invalidate_intensity_values(M_stock.tolist())
h2.hide_wireframe()
apply_palette(h2)

# Name heatmaps, kill auto-legend, and add just two items
def _set_name(series, name):
    for fn in ('setName', 'set_name', 'setLabel', 'set_label'):
        if hasattr(series, fn):
            try: getattr(series, fn)(name); return
            except Exception: pass

_set_name(h1, 'Crypto')
_set_name(h2, 'Stock')

# Create a legend box
# lg = None
# for fn in ('addLegendBox', 'addLegend', 'add_legend_box', 'add_legend'):
#     if hasattr(chart, fn):
#         lg = getattr(chart, fn)()
#         break

# if lg is not None:
#     # Turn OFF automatic entries to avoid duplicates
#     for fn in ('setAutoEntries', 'set_auto_entries', 'setAutomaticEntries', 'set_automatic_entries'):
#         if hasattr(lg, fn):
#             try: getattr(lg, fn)(False)
#             except Exception: pass
#     # If there’s a clear() API, use it
#     for fn in ('clear', 'clearItems', 'clear_items'):
#         if hasattr(lg, fn):
#             try: getattr(lg, fn)()
#             except Exception: pass

    # # Ensure the series themselves won't auto-register elsewhere
    # for s in (h1, h2):
    #     for fn in ('setShowInLegend', 'set_show_in_legend', 'setVisibleInLegend'):
    #         if hasattr(s, fn):
    #             try: getattr(s, fn)(False)
    #             except Exception: pass

    # Now add exactly two entries
    # try:
    #     lg.add(h1)
    #     lg.add(h2)
    # except Exception:
    #     pass

chart.open()
